Peripheral Pump
Description
maximum operating depth up to 5m below water level
fluid temperature up to 40°C
maximum diameter of suspended solids Φ4mm
maximum emptying level 40mm from the bottom
100% Copper winding
Plastic impeller
Single/Three-phase, 50/60Hz (on demand)
Stainless steel mechanical seal (graphite to ceramic)
Plastic pump body
C&U bearing or local bearing
With thermal overload protector
Anti-rust shaft (Hi-Cr plated or welded stainless steel)
